Aurora Model ATW-15-52-36-4 Single Drum Hydraulic Winch
( Two available )
Powered by; (4) Hydraulic motors requiring 110 G.P.M. @ 2500 P.S.I. total
Manufactured 1993 no corrosion, Haven't been cut up.
Line pull:
100,000 Lbs. S.L.P. @ Stall 1st Layer
70,000 Lbs. S.L.P. @ Top Layer
Cable capacity:
5,300Ft. x 1" Wire rope
4,261Ft. x 1-1/8" Wire rope
3,391Ft. x 1-1/4" Wire rope
2,834Ft. x 1-3/8" Wire rope
2,387Ft. x 1-1/2" Wire rope
1,976Ft. x 1-5/8" Wire rope
1,725Ft. x 1-3/4" Wire rope
Skid dimensions: 84-1/2" width x 52-5/8" depth
Overall dimensions: 95-1/2" width x 76-1/2" depth x 74-3/4" height
Weight: 17,000 Lbs.
Unit is available as removed F.O.B Morgan City, La. Gears are in "excellent" condition. The level wind is currently set for 1" wire rope.
PRICE: $38,000.00 F.O.B. Morgan City, La.
